Place of Origin: |
China |
Brand Name: |
Navector |
Model Number: |
NRS1000-2600 |
Certification: |
CE, ISO |
Minimum Order Quantity: |
1 |
Price: |
6500-25000 |
Packaging Details: |
Inner Package: Plastic wrap Master Shipper: Standard shipping wooden case |
Delivery Time: |
25 working days |
Payment Terms: |
70%deposite before producing and 30% balance before shipping out |
Supply Ability: |
50-100 sets/month |
Quick Detail:
Other Name: Rotary sifter,Tumbler, Rotary sieve
Function: screening, classifying, de-dusting, Scalping
Description:
Control screening, classifying, de-dusting of dry material
Meet high feed rates, large output, high-density sieving
5-10 times sieve life than usual sieving machine
For sphere, cylinder, flake and irregular shape materials
For precise separation of material in 1-6 decks
Feed rates from 10 kg/hr up to 50 t/hr
Available with mesh sizes of 20 microns to 20 mm
100% dustproof
Tag:
Tumblering machine
Sieving precision
Difficult to sieve
Spec\NRS Model |
1000 |
1200 |
1500 |
1800 |
2300 |
Screening Area (m²) |
0.785 |
1.13 |
1.68 |
1.9 |
2.12 |
Diameter (mm) |
1010 |
1250 |
1490 |
1810 |
1950 |
Motor Power (kw) |
1.1 |
2.2 |
4 |
4 |
4 |
Weight (kg): |
850 |
1000 |
1340 |
1450 |
1530 |
Voltage |
3 phase, 380V, 50HZ or 3 phase, 415V, 50HZ.(Customized) |
||||
1 Deck Height (mm) |
936 |
1262 |
1285 |
1385 |
1435 |
2 Decks Height (mm) |
1048 |
1375 |
1398 |
1498 |
1528 |
3 Decks Height (mm) |
1159 |
1488 |
1511 |
1611 |
1644 |
4 Decks Height (mm) |
1271 |
1601 |
1624 |
1724 |
1745 |
5 Decks Height (mm) |
1383 |
1714 |
1737 |
1837 |
1859 |
Specification |
Capacity |
Feed Sizes |
20 μm – 20 mm |
Feed Rates |
1 kg/h – 50.000 kg/h |
Bulk Densities |
20 – 10.000 g/l |
Mesh Openings |
20 μm – 20 mm |
Screens Usable |
Stainless steel wire or perforated plates |
No. of Decks |
1 – 5 |
Mesh Cleaning |
Jumping balls/rings, Rotating brush, Ultrasound |
Speed Range |
180 – 280 min–1 |
Screen Movement |
3-dimensional, settable |
Acceleration |
1.3 – 1.8 g / 60 – 80 mm horizontal & 5 – 40 mm vertical |
Materials |
Carbon steel, stainless steels 304/316 |
Machine Surface Treatment |
Painted, brushed or mirror polished |
Fiction free
Higher precision, larger capacity
Difficult to sieve solution
Longer life time
Pharmaceuticals
Chemicals
Ceramics
Coatings
Powder Metallurgy
Abrasive
Starch
